TYPE : Very high-output, passive/bi-amp two-way system
FREQUENCY RESPONSE : 55Hz-18kHz ± 3dB
10dB @ 45Hz
DRIVERS :
15 inch (380mm)/4 inch (100mm) voice coil, long- excursion, neodymium magnet LF driver
1.4 inch (35mm) exit/3 inch (75mm) voice coil, titanium dome, neodymium magnet HF compression driver
RATED POWER (1) :
LF: 600W AES, 2400W peak
HF: 80W AES, 320W peak
SENSITIVITY (2) :
FR: 99dB
LF: 100dB
HF: 108dB
MAXIMUM SPL (3) :
FR: 126dB continuous, 132dB peak
LF: 127dB continuous, 133dB peak
HF: 127dB continuous, 133dB peak
NOMINAL IMPEDANCE :
FR/LF: 8Ω
HF: 16Ω
DISPERSION (-6DB) :
80° horizontal
50° vertical user rotatable
CROSSOVER : 1.75kHz switchable passive/bi-amp
ENCLOSURE : 68 litre, multi-laminate birch ply
FINISH Textured black polyurea coating
PROTECTIVE GRILLE : Black perforated steel, Declon® backed
CONNECTORS : 2 x Neutrik® NL4
INPUT CONNECTIONS :
FR/LF (+,-): 1+,1-
HF (+.-): 2+,2-
FITTINGS :
17 x M8 threaded inserts
1 x Pole mounting socket
2 x Pocket Handle
DIMENSIONS :
(W) 429mm x (H) 690mm x (D) 414mm
(W) 16.9ins x (H) 27.2ins x (D) 16.3ins
WEIGHT : 32Kg (70.5lbs)
