Audio-Technica ATW-RC13 System 10 PRO Rack-Mount Wireless Receiver

SKU: E-6-463

Category:
Pro-Audio

Sub-Category:
Microphones

The System 10 PRO ATW-RC13 from Audio-Technica is a half-rack chassis that allows you to mount one or two ATW-RU13 receiver units (available separately) to create a wireless receiver setup that is easily rackmounted in portable flight cases or permanent installations. When combined with a transmitter and microphone, the System 10 PRO is well suited for educational facilities, conference rooms, small to mid-sized venues, and houses of worship as well as broadcast studios.

PHP 16,000.00

PHP 9,600.00

This product is currently out of stock on our online store but is available at our physical stores / branches. Check out our store locator to find and contact a branch near you.

The System 10 PRO ATW-RC13 from Audio-Technica is a half-rack chassis that allows you to mount one or two ATW-RU13 receiver units (available separately) to create a wireless receiver setup that is easily rackmounted in portable flight cases or permanent installations. When combined with a transmitter and microphone, the System 10 PRO is well suited for educational facilities, conference rooms, small to mid-sized venues, and houses of worship as well as broadcast studios.

The receiver units can be released from the chassis and mounted remotely (up to 328' away) via an Ethernet cable (available separately) for improved antenna reception. Up to five chassis (10 receiver units) can be linked using an RJ12 cable, creating a multichannel system with up to 10 channels being used simultaneously.

The easy-to-read display shows the system IDs for the paired transmitters as well as RF signal strength, link statues to additional receivers, and the remaining battery life on the transmitters. Rear-panel connections include balanced XLR and unbalanced 1/4" output connections as well as output level controls and ground-lift switchs to help eliminate audible hum caused by ground loops.

Audio-Technica ATW-RC13 Specification :
System:
Wireless Transmission Digital : 2.4 GHz
Diversity : Frequency, Time & Space Diversity
RF Frequency Band : 2400 to 2483.5 MHz
RF Channel Scanning : Auto-Scan
Max Operating Range: 200' / 61 m (Line of Sight)
Max Microphones per Band: 10
Sample Rate/Resolution : 48 kHz / 24-Bit
Latency : 3.8 ms
Dynamic Range : >109 dB (Typical)
Form Factor : Rackmount
Mounting Options : Rackmount (with Included Hardware)
Rackmount Size : 1 RU (1/2 Rack)
Receiver Module Capacity : 2
Number of Audio Channels : 2
Audio I/O : 1 x XLR 3-Pin Male Balanced Output
1 x 1/4" TS Female Unbalanced Output
Audio Output Level XLR Output:
0 dBV (Balanced)
1/4" Output:
+6 dBV (Unbalanced)
Frequency Response : 20 Hz to 20 kHz (Dependent on Mic)
Network I/O: 1 x RJ12
AC/DC Power Adapter : 12 VDC at 0.5 A (Included)
AC Input Power : 100 to 200 VAC, 50/60 Hz
Display & Indicators : 1 x LCD (RF Level, Sync, Transmitter Battery Status)
Dimensions : 8.3 x 1.7 x 6.7" / 209.8 x 44 x 169.3 mm
Weight : 33.2 oz / 940 g
