Powersoft X8 innovates and evolves the concept of the amplification platform thanks to the integration of a worldwide compatible three-phase power supply and a fully-featured DSP.
The complete digital audio signal management system based on ARM Cortex A-8 processor and TI C6000 DSP platform heralds new and innovative level of signal processing, providing non-boolean routing and mixing, multi-stage equalization with raised-cosine, IIR and FIR filters, delay up to 2s in input processing and 100ms for time alignment, gain and polarity adjustment, crossover, peak limiters, TruePower limiters, and Active DampingControl.
The power supply permits worldwide AC acceptance and direct connection to any regional power line configuration: it is now suitable for Single Phase, Bi-Phase, or Three Phase operation from 85 VAC up to 440 VAC without the need for manual selection. True Three Phase load balancing is directly achievable by the unit without any complex load assignment in the power distribution system design.
Features:
A robust 6,000W, 8-ch amplifier for live sound reinforcement and commercial installations
TI C6000 processing provides high-grade EQ, crossover, time delay, cable compensation, and limiting capabilities
Dual-24-bit/48kHz Tandem architecture yields flawless AD/DA conversion
Flexible routing and mixing through an internal 8-in/8-out matrix
8 input channels with analog and digital connectors
16-in/8-out redundant Dante connectivity
Comprehensive system protections
Automatic input switching in case of signal failure
Non-Boolean channel routing and intuitive signal grouping
Supports full remote control and monitoring through ArmoníaPlus software
Power supply is adaptable for single-, 2-, or 3-phase operation from 85–440 VAC
Automatic switching and balancing eliminates the need for complex load assignments
Power limiters remove the necessity for costly power sequencers
