Adam Audio A4V Active Studio Monitor

SKU: E-5-1097

Brand:
ADAM Audio

Category:
Pro-Audio

Sub-Category:
Monitors

Designed for small studio spaces, short listening distances and immersive multi-speaker configurations, the A4V delivers accurate, full-bodied sound in a compact form factor.

PHP 41,700.00

PHP 35,445.00

This product is currently out of stock on our online store but is available at our physical stores / branches. Check out our store locator to find and contact a branch near you.

QUALITY COMPACTED

The A4V is a two-way speaker incorporating a 4-inch long-throw woofer made from the same Multi-Layer Mineral (MLM) fibers as other A Series speakers plus the classic X-ART tweeter. Onboard DSP-based tuning capabilities let you easily dial in the perfect sound for your space.

With a frequency range of 52 Hz to 45 kHz, the A4V can accommodate a broad spectrum of audio applications—from producing podcasts to mixing string quartets—and will fit well within immersive and 3D setups.

Product Description

Designed for small studio spaces, short listening distances, and immersive multi-speaker configurations, the A4V delivers accurate, full-bodied sound in a compact form factor. The A4V is a two-way speaker incorporating a 4-inch long-throw woofer made from the same Multi-Layer Mineral (MLM) fibers as other A-Series speakers plus the classic X-ART tweeter. Onboard DSP-based tuning capabilities let you easily dial in the perfect sound for your space. With a frequency range of 52 Hz to 45 kHz, the A4V can accommodate a broad spectrum of audio applications from producing podcasts to mixing string quartets and will fit well within immersive and 3D setups.

HPS Waveguide Technology

The Adam Audio HPS (high-frequency propagation system) waveguide technology enables tweeters to disperse sound with controlled consistency, broad on the horizontal axis but tightly focused in the vertical plane.

Rotatable HPS Waveguide and X-ART Tweeter

The A Series HPS Waveguide is made from a new glass fiber polymer compound that helps create a clear sound, free of unwanted resonance. The Adam Audio X-ART tweeter is at the heart of the rotatable HPS

waveguide. Handmade in Germany, the X-ART tweeter provides precise transient responses and reproduces the finest sonic details. This X-ART tweeter is used in this speaker, providing a detailed, consistent sound across the product line.

Multi-Layer Mineral Woofer

The A4V's woofer is constructed with a unique blend of mineral stone fibers that have been baked together to create a lightweight but highly stable material. By combining this material with a new magnet system, this woofer produces high output with low distortion, delivering a clean low-end.

General Data

Display: Front panel multi-color LED

Cabinet Design: Dual front ported

Cabinet Material: Vinyl wrapped MDF and painted MDF front panel

Mounting options: Threaded inserts on the bottom of the cabinet (4 x M8)

Power consumption (max, idle, sleep): 220 W, 10 W, 3.5 W

AC Input Voltage: 100 – 240 V, 50/60 Hz

Power Rating: 300 W max.

Operating Conditions: -10° C to +40° C (+14° F to +104° F); <75 % RH, non-condensing

Weight: 5.8 kg (12 lbs 13 oz)

Dimensions (Height x Width x Depth): 268 mm x 158 mm x 220 mm (10 1/2″ x 6 1/4″ x 8 5/8“)

Warranty: 5 years (2 years warranty plus 3 years optional with product registration)

Delivery Contents: A4V loudspeaker, power cable, Quick Start Guide

Audio Input Connectors

Analog: XLR, RCA

Input Impedance: 9 kOhm / 3.3 kOhm

Max. Input Level: +19 dBu

Amplification

Woofer

  • Amplifier Type: PWM
  • Peak (10% THD, limiter deactivated): 110 W
  • RMS (1% THD, limiter deactivated): 90 W

Tweeter

  • Amplifier Type: Class A/B
  • Peak (10% THD, limiter deactivated): 20 W
  • RMS (1% THD, limiter deactivated): 15 W

Control Options [via Network]

Networking Connector: RJ45

Connection Type: Ethernet

Communication Protocol: OCA using standard IP data

Control Software: A Control (Windows and MacOS available)

Room Adaption Options: Backplate, Extended, Sonarworks SoundID Reference integration

Advanced Room Adaptation: 6 x PEQ, Level, Delay

Third-party Calibration Compatibility: Import from Sonarworks SoundID Reference
