TYPE: Compact, cardioid subwoofer
FREQUENCY RESPONSE: 43Hz – 150Hz ±3dB, -10dB @ 34Hz
DRIVERS:
18 in (460mm)/4 in (100mm) voice coil, long excursion, ferrite magnet, waterproof cone
14 in (356mm)/3.5 in (88mm) voice coil, long excursion, neodymium magnet, waterproof cone
RATED POWER:
18 in: 1000W AES, 4000W peak
14 in: 800W AES, 3200W peak
SENSITIVITY: 104dB
MAXIMUM SPL: 140dB peak
NOMINAL IMPEDANCE:
18 in: 8Ω
14 in: 8Ω
DISPERSION (-6DB): Cardioid
ENCLOSURE: Multi-laminate birch ply
FINISH: Textured black polyurea
PROTECTIVE GRILLE: Black HEX perforated steel
CONNECTORS: 2 x NL4
PIN CONNECTIONS (INPUT): 18 in: +1, -1; 14 in: +2, -2
PINS CONNECTIONS (LINK): 18 in: +1, -1; 14 in: +2, -2
FITTINGS:
Two skids on base, with mating channels on top
M20 top-mounted thread plate for pole mounting
Two bar handles on each side
Four fittings for optional transit cover
DIMENSIONS (INCL SKIDS):
(W) 650mm x (H) 611mm x (D) 812mm (940mm incl castors)
(W) 25.6in x (H) 24.1in x (D) 32.0in (37.0in incl castors)
WEIGHT: 75kg (165lbs), 78kg (172 lbs) incl castors
