AES3 I/O cards provide a convenient solution for digital patching from a dLive system to system PA, monitor amps and speaker controllers, or for console combining. Four different cards are offered to fit a wide variety of I/O requirements: 2 in / 8 out, 4 in / 6 out, 6 in / 4 out, and 10 out. The cards’ output sample rate is switchable between 96kHz, 88.2kHz, 48kHz and 44.1kHz, while the inputs provide sample rate conversion from 32kHz to 192kHz.
Features:
Choice of AES3 cards
4in 6out (M-DL-AES4I6O-A)
10out (M-DL-AES10O-A)
6in 4out (M-DL-AES6I4O-A)
2in 8out (M-DL-AES2I8O-A)
Switchable sample rate (96kHz, 88.2kHz, 48kHz and 44.1kHz)
Input SRC 32kHz to 192kHz
Option to sync from first AES input
