The AD610 ShowLink Wireless Access Point from Shure enables real-time remote control of all ShowLink-enabled Axient transmitters, including both ADX and AXT series models. The access point allows comprehensive management of transmitter parameters from the receiver or Wireless Workbench using 2.4 GHz (IEEE 802.15.4) wireless communication. All parameter changes occur without interruption to the performer.
Multiple access points can extend the operational range or increase the number of transmitters supported on the ShowLink network. The access point features true diversity antenna inputs along with mounting points for 1/4-inch-20 and M6 x 1.0 threads. A power supply is not included.
Features:
ShowLink access point for Axient wireless systems (analog and digital)
Enables real-time wireless remote control for up to 24 transmitters (per access point)
Adjust gain levels, change frequencies, mute signals, and more
Automatic channel selection scans the entire 2.4GHz range to find the best channel
Automatic frequency agility shifts the whole network to a better channel if signals begin to degrade
Powered via Power over Ethernet or external power supply
Built-in threading for permanent installation, plus versatile mounting options for microphone stand adapters
Wide coverage area is equivalent to the range of Axient transmitters
Automatic transfer between multiple access points makes it easy to extend your range
Coverage area can be enhanced by adding a directional antenna (sold separately)
