MAX OUTPUT POWER :
EIA AT 1KHZ AND 1% THD
8Ω PER CHANNEL 1400 W
4Ω PER CHANNEL 2600 W
2Ω PER CHANNEL 2800 W
DISTORTION
THD FROM 0.1W TO FULL POWER : <0.05% (typically)
INTERMODULATION SMPTE : <0.05% (typically)
INTERMODULATION DIM 30 : <0.05% (typically)
S/N RATIO : > 112dBA (20Hz to 20kHz)
DAMPING FACTOR (8 OHM) : > 5000 (20Hz – 200Hz)
SLEW RATE : 50V/µs
INPUTS
GAIN SELECTABLE (DB) : 26, 29, 32, 35
FRONT PANEL
DISPLAY : Interactive LCD Matrix
INDICATORS
2 x Multi-function 7 segment
LED Bargraph
MENU NAVIGATION : 4 x Digital Push Button
NETWORK : 2 x RJ45
DATA STORAGE & TRANSFER : Smart Card Reader
REAR PANEL
INPUT CONNECTORS :
2 x Neutrik XLR (female) Inpu
2 x Neutrik XLR (male) Link
OUPUT CONNECTORS : 2 x Neutrik Speakon
LINK SWITCH : Channel A-B Link
DATA PORT : RS485 Via RJ45
POWER
OPERATION VOLTAGE : AC: 95-265V (50/60Hz)
DIMENSIONS
WIDTH : 483mm (19ins)
HEIGHT : 48mm (1.75ins) 1U
DEPTH (INCL. HANDLES) : 360mm (14.2ins)
WEIGHT : 8kg (17.6lbs)
